Description
TP-LD51 48V 5.3kW 135AH Lithium Battery, featuring modular design, remote OTA upgrades, and long-lasting LiFePO4 technology for reliable energy storage.
Technical Specifications
| Battery Type | LFP |
|---|---|
| Battery Component | 1P16S |
| Nominal Voltage | 51.2 V |
| Operating Voltage Range | 42.4 ~ 57.6 V |
| Rated Capacity | 100 Ah |
| Nominal Energy | 5.12 kWh |
| Recommended Current | 100 A |
| Max. Current | Charge: 100 A, Discharge: 135 A |
| Peak Current | 200 A (10s, 25°C) |
| Cycle Life | ï¼6000 Cycles (25â ±2â, 0.2C / 0.2C, 90%DOD, 70%EOL) |
| Communication Interfaces | CAN / RS485 |
| HMI | 3.5 inch LCD touchscreen + Status Light + SOC power indicators |
| Operation Temperature | Charge: 0 ~ 55°C, Discharge: -20 ~ 55°C |
| Storage Temperature | -20 ~ 30°C (12 months), 30 ~ 60°C (6 months) |
| Single String Quantity | 16 pcs |
| Dimension (W x H x D) | 335 x 626 x 169 mm |
| Weight | 41.5±1 kg |
| Installation Type | Wall / Floor / Rack mounting |
| Enclosure Protection | IP40 |
| Cooling Concept | Natural cooling |
| Humidity | 20 ~ 85% RH (non-condensing) |
| Altitude | <3000 m |
| Certification | IEC 62477, IEC 62619, IEC 60730, IEC 63056, IEC 61000, UN38.3 |
| Warranty | 5 Years |
