Description
GoodWe LVMT Series is an efficient solar inverter response to South American market needs. Suitable for medium and large scale commercial rooftops.
Key Features
- Four MPPTs Maximize Output: Improve your energy harvest with four MPP trackers to minimize output losses caused by partial shading and other mismatch effects.
- High Generation: With 180% DC input oversizing capability, the LVMT allows users to significantly expand the solar array and drive increased power output even under low solar radiation.
Technical Specifications
GW30KLV-MT
| Max. Input Voltage (V): | 800 |
|---|---|
| Max. Input Current per MPPT (A): | 33/33/22/22 |
| Number of MPP trackers/Number of Strings per MPPT: | 4/3-3-2-2 |
| Max. Efficiency : | 98.7% |
| Nominal Output Voltage (V) : | 220, 3L/N/PE or 3L/PE |
GW35KLV-MT
| Max. Input Voltage (V): | 800 |
|---|---|
| Max. Input Current per MPPT (A): | 33 |
| Number of MPP trackers/Number of Strings per MPPT: | 4/3 |
| Max. Efficiency : | 98.8% |
| Nominal Output Voltage (V) : | 220, 3L/N/PE or 3L/PE |
GW50KLV-MT
| Max. Input Voltage (V): | 800 |
|---|---|
| Max. Input Current per MPPT (A): | 44 |
| Number of MPP trackers/Number of Strings per MPPT: | 4/4/4/4 |
| Max. Efficiency : | 98.7% |
| Nominal Output Voltage (V) : | 220, 3L/N/PE or 3L/PE |
